Butterfly Valve PN 16 ( Lever Operated) LIV-BFV-CI-SGI-003

Lehry Make Butterfly Valve, CI BODY, SGI Iron Disc PN 16 with ISI Mark
Body- C.I IS 210 gr Fg 200
Disc- S. G Iron,
Seat: EPDM
Shaft AISI 410
Manufacturing STD: BS 5155 with ISI marked,
INSP & TEST STD : BS 6755
Operation: Flow control Lever
END connection : Wafer Type to suit ANSI B 16.5
Test Pressure BODY: 24 Kg/cmsq, Seat: 16kg/cmsq
View Brochure
